Earthing Wire H07V-R/H07V-U

Earthing Wire H07V-R/H07V-U

    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U
    • Earthing Wire H07V-R/H07V-U

    Product Details:

    Place of Origin: China
    Brand Name: ECHU
    Certification: CCC,CE,UL
    Model Number: H05V-U H05V-R H05V-K H07V-U H07V-R H07V-K

    Payment & Shipping Terms:

    Minimum Order Quantity: 300M
    Price: USD0.88
    Packaging Details: REELS, DRUM,ROLLS
    Delivery Time: 7-10days
    Payment Terms: T/T
    Supply Ability: 1000000000000METERS
    Contact Now
    Detailed Product Description


    Earthing Wire H07V-R/H07V-UEarthing Wire H07V-R/H07V-UEarthing Wire H07V-R/H07V-UEarthing Wire H07V-R/H07V-U



    Constructions

    Conductor: Class 2 stranded copper conductor (H07V-R)

    Class 1 solid copper conductor(H07V-U)

    Insulation: PVC/D



    Code Designations

    H07V-R/H07V-U



    Applications

    H07V-R/H07V-U is suitable for power and lighting circuits and building wiring.



    Standards

    BS EN 50525-2-31



    Characteristics

    Rated voltage:450/750V

    Max. Operating Temp of Conductor. 70℃

    Min. Ambient Temperature during installation: 0℃

    Min. Bending Radius: 6 x cable O.D if diameter above 25mm

    4 x cable O.D if diameter below 25mm

    Tag:

    single core cable
