Construction
Core Number: Consists of two or more conductors, twisted pairs or groups of twisted conductors twisted together. The conductors or groups of conductors may be laid parallel forming a flat, oval or round cable.
Conductor : Solid or Stranded
Insulation: PVC,PE, SRPVC, PP
Shield or Braid: Optional
Jacket: PVC
Application:Internal wiring of electronic equipment and appliances
Standards
International: UL758 ,UL1581
RoHS
Technical data
Rated voltage:600 V
Rated Temperature:-40℃-105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
Voltage withstand test:AC 2.5kV/1min
