Application Criteria: JIS C3316-2000
Structure describing
Conductor: stranded bare copper or tinned copper , strands meet JIS C3102
Insulation :PVC/CPVC insulation meet GB5023.1 AND GB/T8815
Color: No preferred chromatography, customers can request custom colors
Technical parameters
Rated voltage: 600V or less
Test voltage: 2000V Minimum
bending radius Fixed laying: 4xd (cable diameter)
Mobile installation: 6xd (cable diameter)
Temperature
Fixed laying:-10C-+60C (HKIV 75C)
Flexing : -5c-+60C (HKIV 75C)
Radiation resistance: 8x107cj/kg
Flammability : By GB/T18380 flame test
Key Features Cable's long termallowable working temperature : should not exceed 60c, insulation good mechanial properties, excellent performance. bright colors, good performance, safer to use, uniform insulation thickness and cutting lines, easy peeling. Mobile home appliance, small electric tools, instruments telecommunications equipment, and home automation device and power lighting device mobile connectivity. machinery and equipment can also be used as an internal installation.
