Application criteria: Reference UL21216
Production Description
Conductor: 0.14sqmm to 0.34sqmm: bare coper strands, fine wires>/=0.5sqmm, bare copper strands acc. IEC60228+EN60228, VDE0295, class 6
Insulation: 0.14sqmm to 0.34sqmm, TPE531>/=0.5SQMM: TPE510
Color code: 0.14sqmm to 0.34sqmm: meet the color code
>/=0.5sqmm: black cores with consecutive numbers lines meet EN50334, two or more cores must be added as a yellow-green ground wire
Conductor structure: Each layer through special processing, Wrapped around non-woven belt
Shiled: Bare copper wire wrapped
Sheath: PVC TM5 conform to DIN VDE0281+HD21.1
Jacket Color: black (RAL9005)
Technical parameters
Rated voltage: 0.14sqmm to 0.34sqmm : UL/CSA300V; >/=0.5sqmm UL.CSA 600V
Test voltage: 0.14sqmm to 0.34sqmm: 1500V comply with DIN0281+HD21.2
>/=0.5sqmm 300V comply with DIN0281+HD21.2
Operating voltage: 0.14sqmm--0.34sqmm MAX 250V
0.5sqmm ---1.0sqmm DIN VDE 300/500V
>/=1.5sqmm DIN/VDE 600/1000V
The use of temperature: UL, CSA DIN VDE
Fixed laying: -40 to +80 degree
Mobile installation: -30 to +80 degree
Torsion angle: up to +/-180degree/m
Minimum bending radius
Flexible calbe 12XD
Radiation resistance: 5x..............(Pls to refer to our catalouge)
Flammability: UL VW-1 +CSA FT1 +FT2, IEC60332-1-2+EN60332-1-2
Main features:
Durabletorsion angle can reach+/-180degree good oil resistance, abrasion resistance, cold resistance, eatherability
Typical applications:
Used in different industrial areas connecting cables, such as industrial robots, plant and machine manufacturing, these cables are sutable for higher mechanical stress, in particular friction, highly flexible torsional stresses, while the profit without pulling load, hese cables can be freely bending motion, Can be used for environmental and structural towline unabled use the occasion, can also be used in low temperature, dry and very humid room and unprotedcted places
Validation: ROHS
